Moxa ISD-1130-T RS-422/485 Surge Protector

Overview

The Moxa ISD-1130-T is a compact, plug-and-play RS-422 / RS-485 data-line surge protector designed to protect downstream serial devices from surge events propagating along the data cable. It delivers EN / IEC 61000-4-5 Level 4 (4 kV signal) surge protection with no drivers, no configuration, and no external power – the device sits inline on the serial cable and begins protecting the instant it is connected. Installs inline on an RS-422 or RS-485 cable via the screw-down terminal block; suitable for daisy-chained multi-drop bus topologies where surge protection is fitted near the cable entry to a building or cabinet.

Key Features

• EN / IEC 61000-4-5 Level 4 surge protection (4 kV signal line)
• Serial standards supported: RS-422, RS-485 (2-wire / 4-wire)
• Baudrates from 50 bps to 921.6 kbps – no throttling of the protected link
• Plug and play – no drivers, no firmware, no configuration
• Passive inline design with no external power requirement
• Wide operating temperature range: -40 to 85 deg C (-40 to 185 deg F)
• Compact plastic housing (53 x 37 x 20.6 mm), IP30 rated
• Safety listed to EN 60950-1 / IEC 60950-1
• Environmental and vibration testing to IEC 60068-2-1/-2/-3/-6
• Telcordia (Bellcore) / GB MTBF: 62,642,538 hrs – engineered for decades of field life

Applications

• Industrial field instrumentation cabling exposed to lightning or heavy switching transients
• Modem, fax, and legacy serial peripheral protection in commercial sites
• PLC programming ports and HMI connections subject to site-wide ESD events
• Point-of-sale (receipt printers, barcode readers, cash drawers) surge hardening
• Serial links running between buildings or to outdoor enclosures
• Multi-drop RS-485 bus protection at cabinet or building entry points (ISD-1130-T only)
• Instrumentation benches where equipment cost justifies a low-cost sacrificial front-end

What’s Included

• 1 x ISD-1130-T serial data-line surge protector
• 1 x quick installation guide
• 1 x warranty card

Installation

Designed for desktop or in-line installation. The surge protector is fitted between the host and the field device on the serial cable; no rack, DIN rail, or wall-mount hardware is required. With no drivers or configuration, the device requires no ongoing maintenance and does not appear on the network or to the host operating system – it is fully transparent to the protected link.
